Nsync Pro combines Pixelwix.Inc warp and blend engine with a large scale presentation media player. With a simple user interface and using the system mouse and keyboard the projected output image can be mapped on any kind of projection screen. Overlaps and soft edge blending between projected images can be adjusted using the fine-grained controls and gamma functions. A color correction per projector can be applied to match the color profiles among different projectors.
Nsync Pro ultimate gives the added supports of camera calibration files. A camera can be used to automatically calculate the geometrical correction and soft-edge blending. Using a standard HD webcam, users can create perfect and seamless multi projector setups.
Nsync Pro supports up to 16 projectors per PC, which can be configured in different horizontal and vertical stacking.
Nsync Pro has the ability to scale and sync media over many pc’s for extremely large media playback.
Full NDI and Spout integration.
Built-in support for 400+ media types and codecs.
Streaming from web inputs and capture from hardware cards.
Hardware decoding support (DX9, DX11, CUDA, NVDec)
Special Pause and Goto play items for any show control
Timeline and show-control actions (DMX, PJLink, UDP, Serial Port, ....
Synchronized Master/Slave Multi-PC playback
HTTP and TCP/CMD remote control interface
Responsive HTML/Web interface for playback control.
Simple user interface for mapping the projected output to kind of projection screen
Fine-grained control for overlaps, soft-edge blending and gamma
Color correction and color profile per projector
Up to 16 projectors per PC, in different horizontal and vertical alignment
Auto-alignment using AutoBlend .
And many more...
The following is the required minimal configuration:
PC with 2.0 Ghz or higher processor (32bit or 64 bit)
2 Gb or more RAM
A moderate graphics card (NVIDIA or AMD/ATI)
For creating a wide multi projector display in windows 7, Windows 8 or Windows 10 desktops, the following products are required:
NVIDIA surround 2D support for NVIDIA graphical cards
ATI Eyefinity support for ATI graphical card
Or Matrox DialHead2GO or TrippleHead2GO / Quadhead2go external hardware box
Or Nvidia Quadro graphics card with mosaic mode
A common HD webcam (Ex: Logitech Webcam PRO 9000, Logitech HD Pro Webcam C920, etc.)
